T01-00425PAA
TT Thin Section Turntable Bearings
Dimensions: Bore (Inner) Diameter: 3.500"； Outer Diameter: 5.000"； Width (Thickness): 0.25";
REQUEST FOR QUOTE
Product Attributes
| Bearing Type | Ball | |
| For Load Direction | Four Point | |
| Construction | Single Row | |
| Part Number | T01-00425PAA | |
| gear | no gear | |
| Bore Dia (d) | 3.500 | |
| Outer Dia (D) | 5.000 | |
| Inner Land | 4.148 | |
| Oueter Land | 4.356 | |
| Width (B) | 0.25 | |
| Inner Bolt Circle | 3.813 | |
| Number of holes | 12 | |
| Outer Bolt Circle | 4.688 | |
| Gear pitich diameter(in) | ||
| Number of teeth | ||
| Dynamic(lbs) | Thrust | 1;210 |
| Radial | 750 | |
| Moment | 1;200 | |
| Static (lbs) | Thrust | 3;220 |
| Radial | 1;290 | |
| Moment | 2;740 | |
| Static Torque | 7.4 | |
| Weight (lbs) | 0.67 | |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Thin Section Bearings T01-00425PAA ? TT Thin Section Turntable Bearings Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
