NCF 3010 CV High-capacity cylindrical roller bearings
Dimensions: Bore (Inner) Diameter: 50 mm； Outer Diameter: 80 mm； Width (Thickness): 23 mm;

REQUEST FOR QUOTE

Product Attributes

Product Number	NCF 3010 CV
Bore diameter	50 mm
Outside diameter	80 mm
Width	23 mm
Basic dynamic load rating	76.5 kN
Basic static load rating	98 kN
Fatigue load limit	11.8 kN
Reference speed	4000 r/min
Limiting speed	5000 r/min
Mass	0.43 kg
Shoulder diameter of inner ring	59 mm
Shoulder diameter of outer ring	68 mm
Raceway diameter	72.33 mm

Print PDF
Request a 3D CAD Model if you need special bearings - design custom bearings

What are the types of cylindrical roller bearing NCF 3010 CV ? High-capacity cylindrical roller bearings Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:Negotiation
Price:Negotiation

Fast Delivery √
Best Quality √
Good Price √
