33113 R
Single row tapered roller bearing with flanged outer ring
Dimensions: Bore (Inner) Diameter: 110 mm； Outer Diameter: 34 mm； Width (Thickness): 88.3 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | 33113 R |
| Bore diameter | 110 mm |
| Outside diameter | 34 mm |
| Total width | 88.3 mm |
| Shoulder diameter of inner ring | 116 mm |
| Width of outer ring | 26.5 mm |
| Flange Thickness (C1) | 5.5 mm |
| Chamfer minimum dimension of inner ring (r1,2) | 1.5 mm |
| Chamfer minimum dimension of outer ring (r3,4) | 1.5 mm |
| Distance side face to pressure point (a) | 25 mm |
| Basic dynamic load rating (Cr) | 175 kn |
| Basic static load rating (Cor) | 208 kN |
| Fatigue load limit (Pu) | 24 kN |
| Reference speed | 4800 r/min |
| Limiting speed | 5600 r/min |
| Mass | 1.3 kg |
| Limiting value (e) | 0.4 |
| Axial load factor (Y) | 1.5 |
| Axial load factor (Y0) | 0.8 |
| Maximum diameter of shaft abutment (da) | 74 mm |
| Minimum diameter of shaft abutment (db) | 75 mm |
| Maximum Radius of shaft fillet (ra) | 1.5 mm |
