32309 BR
Single row tapered roller bearing with flanged outer ring
Dimensions: Bore (Inner) Diameter: 100 mm； Outer Diameter: 38.25 mm； Width (Thickness): 76.1 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | 32309 BR |
| Bore diameter | 100 mm |
| Outside diameter | 38.25 mm |
| Total width | 76.1 mm |
| Shoulder diameter of inner ring | 106 mm |
| Width of outer ring | 30 mm |
| Flange Thickness (C1) | 7 mm |
| Chamfer minimum dimension of inner ring (r1,2) | 2 mm |
| Chamfer minimum dimension of outer ring (r3,4) | 1.5 mm |
| Distance side face to pressure point (a) | 29 mm |
| Basic dynamic load rating (Cr) | 166 kn |
| Basic static load rating (Cor) | 176 kN |
| Fatigue load limit (Pu) | 20 kN |
| Reference speed | 5000 r/min |
| Limiting speed | 6700 r/min |
| Mass | 1.55 kg |
| Limiting value (e) | 0.54 |
| Axial load factor (Y) | 1.1 |
| Axial load factor (Y0) | 0.6 |
| Maximum diameter of shaft abutment (da) | 56 mm |
| Minimum diameter of shaft abutment (db) | 55 mm |
| Maximum Radius of shaft fillet (ra) | 2 mm |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Tapered roller bearings 32309 BR ? Single row tapered roller bearing with flanged outer ring Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
