32030T112 X/DB
Tapered roller bearings& single row& matched back-to-back
Dimensions: Bore (Inner) Diameter: 150 mm； Outer Diameter: 225 mm； Width (Thickness): 112 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | 32030T112 X/DB |
| Bore diameter | 150 mm |
| Outside diameter | 225 mm |
| Total width | 112 mm |
| Shoulder diameter of inner ring | 187 mm |
| Width of outer ring | 88 mm |
| Chamfer minimum dimension of inner ring (r1,2) | 3 mm |
| Basic dynamic load rating (Cr) | 782 kn |
| Basic static load rating (Cor) | 1320 kN |
| Fatigue load limit (Pu) | 132 kN |
| Reference speed | 1800 r/min |
| Limiting speed | 2600 r/min |
| Mass | 14 kg |
| Limiting value (e) | 0.46 |
| Axial load factor (Y0) | 1.4 |
| Minimum diameter of shaft abutment (db) | 165 mm |
| Minimum width of space required in housing on small side face (C | 12 mm |
| Width of spacer ring (l) | 16 |
| Width of lubrication groove (b) | 4 |
| Diameter of lubrication hole (K) | 3 |
| Chamfer minimum dimension of outer ring (r5) | 1 |
| Axial load factor (Y1) | 1.5 |
| Axial load factor (Y2) | 2.2 |
| Maximum Radius of housing fillet (ra) | 3 |
| Maximum Radius of shaft fillet (rc) | 1 |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Tapered roller bearings 32030T112 X/DB ? Tapered roller bearings& single row& matched back-to-back Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
