32008 XR
Single row tapered roller bearing with flanged outer ring
Dimensions: Bore (Inner) Diameter: 68 mm； Outer Diameter: 19 mm； Width (Thickness): 54.7 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | 32008 XR |
| Bore diameter | 68 mm |
| Outside diameter | 19 mm |
| Total width | 54.7 mm |
| Shoulder diameter of inner ring | 72 mm |
| Width of outer ring | 14.5 mm |
| Flange Thickness (C1) | 3.5 mm |
| Chamfer minimum dimension of inner ring (r1,2) | 1 mm |
| Chamfer minimum dimension of outer ring (r3,4) | 1 mm |
| Distance side face to pressure point (a) | 14 mm |
| Basic dynamic load rating (Cr) | 64.7 kn |
| Basic static load rating (Cor) | 71 kN |
| Fatigue load limit (Pu) | 7.65 kN |
| Reference speed | 7500 r/min |
| Limiting speed | 9500 r/min |
| Mass | 0.29 kg |
| Limiting value (e) | 0.37 |
| Axial load factor (Y) | 1.6 |
| Axial load factor (Y0) | 0.9 |
| Maximum diameter of shaft abutment (da) | 46 mm |
| Minimum diameter of shaft abutment (db) | 47.5 mm |
| Maximum Radius of shaft fillet (ra) | 1 mm |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
