30313 R
Single row tapered roller bearing with flanged outer ring
Dimensions: Bore (Inner) Diameter: 140 mm； Outer Diameter: 36 mm； Width (Thickness): 98.7 mm;
REQUEST FOR QUOTE
Product Attributes
| Product Number | 30313 R |
| Bore diameter | 140 mm |
| Outside diameter | 36 mm |
| Total width | 98.7 mm |
| Shoulder diameter of inner ring | 147 mm |
| Width of outer ring | 28 mm |
| Flange Thickness (C1) | 6 mm |
| Chamfer minimum dimension of inner ring (r1,2) | 3 mm |
| Chamfer minimum dimension of outer ring (r3,4) | 2.5 mm |
| Distance side face to pressure point (a) | 27 mm |
| Basic dynamic load rating (Cr) | 240 kn |
| Basic static load rating (Cor) | 228 kN |
| Fatigue load limit (Pu) | 27.5 kN |
| Reference speed | 4000 r/min |
| Limiting speed | 4800 r/min |
| Mass | 2.5 kg |
| Limiting value (e) | 0.35 |
| Axial load factor (Y) | 1.7 |
| Axial load factor (Y0) | 0.9 |
| Maximum diameter of shaft abutment (da) | 84 mm |
| Minimum diameter of shaft abutment (db) | 78 mm |
| Maximum Radius of shaft fillet (ra) | 3 mm |
Print PDF
Request a 3D CAD Model
if you need special bearings - design custom bearings
What are the types of Tapered roller bearings 30313 R ? Single row tapered roller bearing with flanged outer ring Manufacturing Service . Get Your Free, Instant price, design review, stock and delivery time.
Min.Order Quantity:NegotiationPrice:Negotiation
